Polyurethane Soft Foam Stress Ball For Kids Making Low Pressure PU Foaming Machine

Short Description:


Product Detail

Product Tags

Product Name: Pu Injection Moulding Machine Injection Output: 5-20g/s
Foam Application: PU Toy Ball Input Power: Three-phrase Five-wire,380V 50HZ
Rated Power: About 8KW Raw Material: Flexible Foam Polyol+Isocyanate
High Light:

Stress Ball PU Foaming Machine

,

Stress Ball Polyurethane Foaming Machine

,

20g/s Polyurethane Foaming Machine

Polyurethane Soft Foam Stress Ball For Kids Making Low Pressure PU Foaming Machine Product Description of low pressure foam machine: SPUF2J6-36 type low pressure foaming machine is newly developed by Lingxin company based on learning and absorbing advanced techniques abroad, which is widely employed in the production of automotive parts, automotive interior, toys, memory pillow and other kinds of flexible foams like integral skin, high resilience and slow rebound , etc. This machine has high repeat injection precision, even mixing, stable performance, easy operation, and high production efficiency, etc.

No. Item Technical Parameter
1 Foam application Flexible foam
2 raw material viscosity(22℃) ~3000CPS ~1000MPas
3 Injection Output 5-20g/s
4 Mixing ratio range 100:28~48
5 Mixing head 2800-5000rpm, forced dynamic mixing
6 Tank Volume 30L
7 Metering pump A pump: JR6 Type B Pump: JR3.6 Type
8 Compressed air requirement dry, oil free P:0.6-0.8MPa Q:600NL/min(Customer-owned)
9 Nitrogen requirement P:0.05MPa Q:600NL/min(Customer-owned)
10 Temperature control system heat:2×3.2Kw
11 Input power three-phrase five-wire,380V 50HZ
12 Rated power about 8KW
13 swing arm 90°Rotatable swing arm, 0.7m(length customizable)

 Features of pu injection machine: 1. For sandwich type material bucket, it has good heat preservation2. The adoption of PLC touch screen human-computer interface control panel makes the machine easy to use and the operating situation was absolutely clear.3. Head connected with the operation system, easy for operation4. The adoption of new type mixing head makes the mixing even, with the characteristic of low noise, sturdy and durable.5. Boom swing length according to the requirement, multi-angle rotation, easy and fast
6. High precision pump lead to measuring accurately
7. Easy for maintenance, operation and repair.
8. Low energy consumption. Applications:      Feedbacks:
