Precise Metering Wall Panel 16g/s PUF Insulation Filling Machine

Short Description:


Product Detail

Product Tags

Processing Type: Foaming Machine, Foaming Machine Condition: New
Product Type: Foam Net Machine Type: Injection Machine
Voltage: 380V Dimension(L*W*H): 4100(L)*1250(W)*2300(H)mm
Power (kW): 9kW Weight (KG): 1000 KG
Warranty: 1 YEAR After-sales Service Provided: Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support
Key Selling Points: Automatic After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: Turkey, Pakistan, India Showroom Location: Turkey, Pakistan, India
Applicable Industries: Manufacturing Plant Strength 1: Self-cleaning Filter
Strength 2: Automatic Feeding System Strength 3: PLC Control System
Strength 4: Precise Metering Foam Type: Flexible Foam
Output: 16-66g/s Tank Volume: 120L
Power: Three-phase Five-wire 380V Name: 3d Wall Panel Machines
Port: Ningbo For 3d Wall Panel Machines
High Light:

9kW PUF insulation filling machine

,

120L high pressure pu machine

,

16g/s PUF Insulation Filling Machine

PUR PU Polyurethane Foam Filling High Pressure Machine For 3D Wall Panel MakingProduct Description: Polyurethane foaming machine, has the economical, convenient operation and maintenance, etc, can be customized according to customer's request various pours out of the machine.
This polyurethane foaming machine uses two raw materials, polyurethane and Isocyanate. This type of PU foam machine can be used in various industries, such as daily necessities, automobile decoration, medical equipment, sports industry, leather footwear, packaging industry, furniture industry, military industry.

No. Item Technical parameter
1 Foam application Flexible Foam
2 Raw material viscosity(22℃) POLY ~2500MPas ISO ~1000MPas
3 Injection pressure 10-20Mpa(adjustable)
4 Output (mixing ratio 1:1) 280~1300g/min
5 Mixing ratio range 1:5~5:1(adjustable)
6 Injection time 0.5~99.99S(correct to 0.01S)
7 Material temperature controlling error ±2℃
8 Repeat injection accuracy ±1%
9 Mixing head Four oil house,double oil cylinder
10 Hydraulic system Output: 10L/min System pressure 10~20MPa
11 Tank volume 500L
15 Temperature control system Heat: 2×9Kw
16 Input power Three-phase five-wire 380V



Product Features of High Pressure PU Machine:

1.Adopting three layer storage tank, stainless steel liner, sandwich type heating, outer wrapped with insulation layer, temperature adjustable, safe and energy saving;
2.Adding material sample test system, which can be switched freely without affecting normal production, saves time and material;
3.Low speed high precision metering pump, accurate ratio, random error within ±0.5%;
4.Material flow rate and presure adjusted by converter motor with variable frequency regulation, high accuracy, simple and rapid ration adjusting;
5.High-performance mixed device, accurately synchronous materials output, even mixture. New leakproof structure, cold water cycle interface reserved to ensure no blockage during long downtime;
6.Adopting PLC and touch screen man-machine interface to control the injection, automatic cleaning and air flush, stable performance, high operability, automatically distinguish, diagnose and alarm abnormal situation, display abnormal factors. Detailed Introduction of Foam Injection Machine Parts:

Material tank: Poly/ Iso tank with 500L, thermostatic control by two layer wall with insulation layer, installing two manual stop valves in delivery outlet,bottom installed with waste valve.

Mixing head: Adopt L type automatic self-cleaning mixing head, needle type nozzle adjustable, V type jet orifice, High-pressure collisional mixing principle ensure mixing effectual.

Chiller: Used to supply cooling water to cooling unit,refrigeration capacity 38700Kcal/h ;(options)

Applications: Compared with other background walls, the soft 3D PU background wall has a very soft texture and soft color, which can well soften the overall space atmosphere in a decorative environment. Due to the special craftsmanship of the soft-covered background wall, including the characteristics and luxury of the material used, it has greatly improved the grade of the entire home space. In addition, the three-dimensional sense of the soft-covered background wall can also greatly improve the grade of the home space. . In addition to the function of beautifying the space, the soft-packed background wall has the functions of sound absorption, sound insulation, anti-collision, shock resistance, fire and flame retardant. The soft background wall is not only beautiful but also very practical.

Our Team:

We have professional team of mechanical engineer, chemical engineer, process engineer, etc, all of them have more than 10 years experience in PU foam filed. Also, we have special sales team, they are young but hard-working and experienced. We can meet any your requirements of the PU foam product, pu mold and PU foam machines.



Visitors and Exhibitions

We participated in many exhibitions of polyurethane raw materials, polyurethane foam products and polyurethane PU foam machines. Our products left a very good impression to everyone at the show, some customers even placed orders on the spot.
