Weatherstrip Profiles 0.1Mpa PU Gasket Dispensing Machine

Short Description:

Product Detail

Product Tags

Processing Type: Foaming Machine, Foaming Machine Condition: New
Product Type: Foam Net Voltage: 380V
Dimension(L*W*H): 4100(L)*1250(W)*2300(H)mm Warranty: 1 YEAR
After-sales Service Provided: Video Technical Support, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Online Support Key Selling Points: Automatic
Applicable Industries: Manufacturing Plant Product Name: Seal Strip Making Machine
Strength 1: Self-cleaning Filter Strength 2: Precise Metering
Feeding System: Automatic Feeding System Control System: PLC Control System
Foam Type: Flexible Foam/ Rigid Foam Output: 16-66g/s
Tank Volume: 120L Power: Three-phase Five-wire 380V
Power: About 9 KW Weight: About 2000kg
Port: Ningbo For Seal Strip Making Machine
High Light:

0.1Mpa polyurethane dispensing equipment


PLC PU Gasket Dispensing Machine


0.1Mpa PU Gasket Dispensing Machine

Polyurethane PU Dispensing Machine For Weatherstrip Profiles Making Introduction Of Coated Polyurethane Foam Seal Casting Machine: The casting machine is used in production line of cladding type sealing strip to produce different kinds of cladding type foam weatherstrip.

Flow Tank Proportion Production Mode Metering Pump Total Power
2-10 g/s 30 L 100:25-40 Continuous A.JR2.4/ B.JR1.2 4.5 KW

Product Features:

1. High precision metering pump, accurate metering, random error within ± 0.5%;2. High Performance anti drooling mixing device with flowback adjusting function, accurate material output synchronization and even mix;
3. Fully automatic control of material injecting time, cleaning frequency, automatic cleaning flush and air purge;
4. Adopting PLC, touch screen man-machine interface, and servosystem to control casting, move as per preset track, accurate positioning;
5. Additional functions optional: remote control, automatic feeding, high viscosity filling pump, automatic cycle during shutdown, mixing head water flush,etc.

Two mixing hands:

High-performance mixing device, precise synchronizing of raw material discharge, uniform mixing; new sealing structure, reserved cold water circulation interface to ensure long-term continuous production is not blocked

Material Tank:

30L autotemperature control three layer stainess steel material tank, automatic stirring with alarm for lack of material

Metering Pump:

The higher precision metering pump is equipped with more accurate, the measurement accuracy error does not exceed ±0.5%; the variable frequency motor is matched with the frequency conversion to adjust the flow rate and pressure of the raw material, the precision is high, and the proportional adjustment is simple and quick. Application: Cladding type sealing strip is composited by four fine quality materials, outer wrapped with PE film, it is good partner of modern household doors and windows with elegant appearance. Features 1. Cladding type weatherseal has more excellent test results than other traditional products in ageing resistance, fatigue
resistance, compression deformation test, compression test, thermal conductivity k value test, water invasion, and water
2. Coated weatherstrip is energy saving and environmental protecting, soundproof and noise reducing, uvioresistant, non-toxic, do not react with any paint or detergent, which meets the needs of green health topics.`   Exhibition&Certifications: Our Service: 1. Professional and patient consulting service to help you find the suitable solution.
2. Further negotiation about the technical details, machine configuration, price basis, payment term and delivery time.
3. Powerful control of the machine production schedule and quality, and keep you posted about details in time.
4. Free training in our plant during machine inspection. Or photos and video of the machine and package for your confirmation before shipment.
5. Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.
6. For technical support, we can help you online by email and phone, also we can send technicians to your site if necessary.
7. For the spare parts, we will supply the parts for free during one year guarantee period, also the parts supplying at original cost after that .
8. We give an accessory box for free.
9. We offer development solutions for raw material formulations.
10. If you need to visit the factory, we will arrange for personnel to pick up the airport.
