Polyurethane Soft C Shaped Memory Foam Pillow Molding Low Pressure PU Filling Machine

Short Description:

Product Detail

Product Tags

Product Name: Pu Injection Moulding Machine Injection Output: 54-216g/s
Foam Application: All Shaped Memory Foam Pillows Input Power: Three-phrase Five-wire,380V 50HZ
Rated Power: About 11KW Raw Material: Flexible Foam Polyol+Isocyanate
High Light:

Memory pillow PU Filling Machine


Pillow Molding PU Filling Machine


216g/s pu foam filling machine

Polyurethane Soft C Shaped Memory Foam Pillow Molding Low Pressure PU Foaming Machine Product Description of polyurethane injection molding machine: SPUF2A25-20 type low pressure foaming machine is newly developed by Yongjia company based on learning and absorbing advanced techniques abroad, which is widely employed in the production of automotive parts, automotive interior, toys, memory pillow and other kinds of flexible foams like integral skin, high resilience and slow rebound , etc. This machine has high repeat injection precision, even mixing, stable performance, easy operation, and high production efficiency, etc.

No. Item Technical Parameter
1 Foam application Flexible foam pillows
2 raw material viscosity(22℃) ~3000CPS ~1000MPas
3 Injection Output 54-216g/s
4 Mixing ratio range 100:28~48
5 Mixing head 2800-5000rpm, forced dynamic mixing
6 Tank Volume 120L
7 Metering pump A pump: GPA3-25 Type B Pump: JR20 Type
8 Compressed air requirement dry, oil free P:0.6-0.8MPa Q:600NL/min(Customer-owned)
9 Nitrogen requirement P:0.05MPa Q:600NL/min(Customer-owned)
10 Temperature control system heat:2×3.2kW
11 Input power three-phrase five-wire,380V 50HZ
12 Rated power about 11KW
13 swing arm Rotatable swing arm, 2.3m(length customizable)

Features of pu injection machine: 1. For sandwich type material bucket, it has good heat preservation2. The adoption of PLC touch screen human-computer interface control panel makes the machine easy to use and the operating situation was absolutely clear.3. Head connected with the operation system, easy for operation4. The adoption of new type mixing head makes the mixing even, with the characteristic of low noise, sturdy and durable.5. Boom swing length according to the requirement, multi-angle rotation, easy and fast
6. High precision pump lead to measuring accurately
7. Easy for maintenance, operation and repair.
8. Low energy consumption. Applications: Also known as viscoelastic foam, memory foam contours in response to heat and pressure. The material provides a supportive, pressure-relieving cradle that makes it ideal for use in pillows.Whether you suffer from neck pain or whether you’re simply looking for a pillow that will support your spine and help you get a better night’s sleep, look no further. Polyurethane foam pillow can meet all your requirements.  Feedbacks:
